SLAM SPECIALTIES air springs are technologically advanced in all areas of design and performance. Bolt pattern compatible with Firestone and other air springs

• Rated at much higher pressures - critical for front end installations on heavy V8 vehicles
• Non-ballooning, stiffer bellows ensure that more force is exerted through the centerline of the airspring to lift the vehicle straight up - this is an important feature of bellow design as the front control arms are at a "mechanically disadvantaged point" when the vehicle is lowered.
• Superior end plate design to all other airsprings making it virtually impossible for separation to occur even when unrestrained at maximum pressure!
• Unique internal bump stop prevents rubber bellow damage from constantly deflating airspring to zero pressure (see image below)

• Capacity per airspring @ 110psi = 4860lbs

  • Rated @ 200psi
  • 8″ diameter bag
  • Minimum height = 2.9"
  • Installed height approx = 6.5"
  • Maximum height = 12.0"
  • Single 1/2″ NPT port
  • Internal bumpstops
  • Non-ballooning design
  • (2) 3/8″-16 Mounting Holes Top
  • (3) 3/8″-16 Mounting Holes Bottom
  • Chemically bonded aluminum/zinc end closure plates
  • Replaces: 25c
  • Sold Individually
  • Designed & Manufactured by Slam Specialties
  • Made in the USA
